By-alarm Plus keypad with display+transp - 03818

03818
Safety / By-alarm Plus / Surface mounting components / Non-modular components

By-alarm Plus keypad with display+transp
By-alarm Plus keypad with monochrome LCD display and transponder actuator, 2 In/Out zones/terminals, 12 VDC power supply, 23 backlit keys, 5 status LEDs, surface mounting

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (766 kb)
• Feuille d’instructions (544 kb)
• Anwendungshinweise (545 kb)
• Bedienungsanleitung (2812 kb)
• User manual (5037 kb)
• Manuel de l'utilisateur (2810 kb)

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Alarm installations, emergency call and signalling

Class
Switchgear for danger detection system

Engaging electronically
Yes

Engaging mental
No

Engaging mechanical
Yes

Engaging biometrical
No

Engaging indication
Yes

Radio system
Yes

Degree of protection (IP)
IP20

Material
Plastic

With contact
Yes

Width
14.030,00 mm

Height
15.030,00 mm

Depth
2.160,00 mm

Compatible with Apple HomeKit
No

Compatible with Google Assistant
No

Compatible with Amazon Alexa
No

IFTTT support available
No

VdS class
None

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352707931

1 NR

15.2x3.4x16 [cm]

318.95 [g]

8007352707948

12 NR

32x23.5x18 [cm]

4,100 [g]
