2P+E 16A universal outlet red - 08410.R

Pdf
Vimar - 08410.R - 2P+E 16A universal outlet red
Vimar - 08410.R - 2P+E 16A universal outlet red

08410.R
Wiring devices / Traditional wiring devices / 8000 / Devices

2P+E 16A universal outlet red
2P+E 16 A 250 V~ SICURY socket outlet, universal, for 2P 2,5 A Europlugs, for 2P and 2P+E 10 A and 16 A Italian standard plugs, for 2P+E 16 A German standard plugs and for 2P 15 A 125 V~ American standard plugs with non-polarized flat blades, red - 2 special modules. Earth connection is not realized with 16 A 2P+E 250 V~ French standard plug

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Red
RAL-number (similar)
3001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
With miniature fuse
No
Mounting method
Flush-mounted
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
49,80 mm
Device height
50,10 mm
Device depth
42,00 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352153110
1 NR
5.1x4.3x5.3 [cm]
58.47 [g]
Barcode Qty 20 NR
8007352153127
20 NR
26.9x11.6x9 [cm]
1,239.2 [g]
