Plate 2M resin snapfix ivory - 08606.A

Pdf
Vimar - 08606.A - Plate 2M resin snapfix ivory
Vimar - 08606.A - Plate 2M resin snapfix ivory

08606.A
Wiring devices / Traditional wiring devices / 8000 / Cover plates

Plate 2M resin snapfix ivory
2-module cover plate for ø 60 mm round mounting boxes, resin, snap fixing, ivory. For mounting frame 08502

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
2
Mounting direction
Horizontal and vertical
Number of units horizontal
2
Number of units vertical
1
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9010
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
83,00 mm
Height
103,00 mm
Depth
6,00 mm
Built-in width
83,00 mm
Built-in height
103,00 mm
Diameter bore hole (opening)
0 mm

01. IMQ - Italy

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352041936
1 NR
8.3x10.3x0.6 [cm]
16.9 [g]
Barcode Qty 20 NR
8007352003583
20 NR
15.8x12.4x9.6 [cm]
394.2 [g]
Barcode Qty 5,760 NR
8007352587700
5,760 NR
120x80x105 [cm]
137,809 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
