Plate 4sp.M alum. snapfix bronze - 08658.BR

08658.BR

8000 / Cover plates / Snap fixing metal cover plates

Plate 4sp.M alum. snapfix bronze
4 special module cover plate for 4-module flush mounting boxes, anodized aluminium, snap fixing, bronze. For mounting frame 08532.S

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devic
Number of units
4
Mounting direction
Horizontal and vertical
Number of units horizontal
4
Number of units vertical
1
Number of modules horizontal (
4
Number of modules vertical (mo
1
Number of gangs
0
With mounting grid
Yes
Suitable for flush-mounted ins
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installa
No
Label space/information surfac
Yes
Material
Metal
Material quality
Aluminium
Halogen free
Yes
Surface protection
Anodised
Surface finishing
Matt
Colour
Bronze
RAL-number (akin)
1036
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
145,00 mm
Height
75,50 mm
Depth
6,00 mm
Built-in width
145,00 mm
Built-in height
75,50 mm
Diameter bore hole (opening)
0 mm
Minimum order quantity: 20 NR

Barcode

8007352076501
1 NR
14.5x7.5x0.6 [cm]
17.2 [g]
8007352076693
20 NR
22x15.9x8.2 [cm]
421 [g]
