2 2P+E 16A USA+EU SICURY outlets white - 09249

Pdf
Vimar - 09249 - 2 2P+E 16A USA+EU SICURY outlets white
Vimar - 09249 - 2 2P+E 16A USA+EU SICURY outlets white

09249
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2 2P+E 16A USA+EU SICURY outlets white
Two 2P+E 16 A 250 V~ SICURY socket outlets, polarized Euro-American standard, white - 3 modules

Product Status
3 - Active

You may also be interested in

09248
09248 - 2P+E 16A USA+EU SICURY outlet white

Drawings

view encumbered art. 09249
PNG DXF
rear view art. 09249
PNG DXF
3D view art. 09249
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of modules (module system)
3
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
67,30 mm
Device height
47,00 mm
Device depth
34,00 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

29. QCERT - Colombia

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352467576
1 NR
5.3x3.9x7.6 [cm]
70.8 [g]
Barcode Qty 20 NR
8007352467583
20 NR
28.1x13.1x11.3 [cm]
1,520 [g]
Barcode Qty 240 NR
8007352641334
240 NR
59x38.5x24 [cm]
19,000 [g]
