IoT dial thermostat 2M carbon matt - 09473.CM

Pdf
09473.CM

Neve Up / Devices / Radiofrequency

IoT dial thermostat 2M carbon matt
Dial thermostat for ambient temperature control, 5(2) A 240 V~ relay output, View Wireless technology on Bluetooth® wireless technology 5.0 for mesh View Wireless system realization, 1 input for outer temperature sensor, supply voltage 100-240 V~ 50/60 Hz, heating and air-conditioning ON/OFF and PID, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, white LED backlighting and brightness regulation, supply voltage 100-240 V 50/60 Hz, carbon matt - 2 modules

Product Status
3 - Active

Class group
Stats, switches and controllers
Class
Room thermostat
Model
Other
Type of power supply
230 V AC
Connection
Three-four-wire
With receiver
No
Measuring range minimum value
0 °C
Measuring range maximum value
40 °C
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
PID
Heating
Yes
Number of heater outputs
1
Cooling
Yes
Number of cooler outputs
1
Differential value
0,00 - 1,00 k
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Other
Mounting method
Other
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Contact type
Normally open contact
Max. contact voltage
240 v
Max. contact load
5 A
Degree of protection (IP)
IP30
Explosion-proof
No
Colour
Anthracite
RAL-number
7016
Height
47,00 mm
Width
44,80 mm
Depth
41,50 mm
Class of the temperature control
IV
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352671409
1 NR
5.7x5.7x7.7 [cm]
81.6 [g]
Barcode Qty 70 NR
8007352671416
70 NR
39.5x30x17 [cm]
6,122 [g]
