1P 10AX 1-way switch mechanism screwless - 14000.FX.0

Pdf

14000.FX.0
Wiring devices / Traditional wiring devices / PLANA / Devices

1P 10AX 1-way switch mechanism screwless
1P 10 AX 250 V~ 1-way switch mechanism, screwless terminals, lightable, to complete with 1, 2 or 3-module button. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
Green
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Push-in clamp
Washing machine switch
No
Device width
22,30 mm
Device height
49,00 mm
Device depth
40,50 mm
Built-in depth
26,10 mm
Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352513679
1 NR
5.1x2.8x5.3 [cm]
22.3 [g]
Barcode Qty 50 NR
8007352513686
50 NR
27x15x12 [cm]
1,201 [g]
