1P NC 10A push button mechanism - 14010.0

Pdf

14010.0
Wiring devices / Traditional wiring devices / PLANA / Devices

1P NC 10A push button mechanism
1P NC 10 A 250 V~ push button mechanism, lightable, to complete with 1, 2 or 3-module button

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
38,70 mm

00. CE Marking - EU

14. TSE - Turkey

19. NOM - Mexico

20. IQC - Argentina

29. QCERT - Colombia

37. Marking - Morocco

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352117273
1 NR
4.1x2.8x5.3 [cm]
24.53 [g]
Barcode Qty 10 NR
8007352263697
10 NR
14.4x9x6 [cm]
280.67 [g]
Barcode Qty 160 NR
8007352642102
160 NR
37.5x30x13.5 [cm]
4,840 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
