2P 32A 1-way switch Silver - 14017.SL

Pdf
Vimar - 14017.SL - 2P 32A 1-way switch Silver
Vimar - 14017.SL - 2P 32A 1-way switch Silver

14017.SL
Wiring devices / Traditional wiring devices / PLANA / Devices

2P 32A 1-way switch Silver
2P 32 A 250 V~ 1-way switch, lightable, with built-in frame for British standard square boxes, to complete with British standard cover plates, Silver. Max 200 W for integrated ballast lamps (IEC 60669-1:2017)

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 14017.SL
PNG DXF
rear view art. 14017.SL
PNG DXF
3D view art. 14017.SL
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
3
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Screw mounting
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
9006
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
32,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Device width
82,50 mm
Device height
82,50 mm
Device depth
32,50 mm
Built-in depth
22,50 mm

00. CE Marking - EU

08. ASTA - UK

31. TISI - Thailand

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352406322
1 NR
8.5x3.9x8.6 [cm]
115.9 [g]
Barcode Qty 10 NR
8007352406339
10 NR
20.7x18.5x9.6 [cm]
1,254 [g]
