Switched connection unit 13A Silver - 14049.SL

Pdf
Vimar - 14049.SL - Switched connection unit 13A Silver
Vimar - 14049.SL - Switched connection unit 13A Silver

14049.SL
Wiring devices / Traditional wiring devices / PLANA / Devices

Switched connection unit 13A Silver
Connection unit 13 A 250 V~ with 2P 1-way switch, cable output, protection fuse, with built-in frame for square British boxes, to complete with 3-module British standard cover plates, Silver

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
5
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Screw mounting
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
9006
Label space/information surface
Yes
Illumination
Optional
Function lighting
Illuminated (on)
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
13,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
82,50 mm
Device height
82,50 mm
Device depth
33,00 mm
Built-in depth
20,40 mm

00. CE Marking - EU

08. ASTA - UK

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352406568
1 NR
8.5x3.9x8.6 [cm]
106.7 [g]
Barcode Qty 10 NR
8007352406575
10 NR
20.7x18.5x9.6 [cm]
1,166 [g]
