Universal MASTER dimmer 230V white - 14135.1

Pdf
14135.1

Plana / Devices / Electronic devices

Universal MASTER dimmer 230V white
Universal-dimmer 230 V~ 50 Hz, phase-cutting, for: 40-400 W incandescent lamps, 40-300 VA electronic transfomers, 10-200 W CFL lamps, 3-200 W LED lamps and LED phase-cutting electronic transfomers, ON/OFF control and built-in or from NO peripheral push buttons regulation, MASTER function for 14137, minimum brightness regulation, visible in darkness, white. Not for Isoset enclosures

  • Easy to see in the dark thanks to the LED light

Product Status
3 - Active

Sheets, Manuals, Documentation


Drawings

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Push button
Type of load
Universal and LED Retrofit
Applicable with button
Yes
Applicable with movement senso
No
Applicable with presence indic
No
Applicable with time switch/ti
No
Applicable with transmission b
No
Applicable with infrared butto
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (akin)
9003
Transparent
No
Suitable for degree of protect
IP40
Nominal voltage
230,00 - 230,01 v
Frequency
50,00 - 50,01 HZ
Control voltage
230,00 - 230,01 v
Nominal power
40 - 400 VA
Connection type
Screwed terminal
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
50,70 mm
Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352554917
1 NR
5.1x4.3x5.3 [cm]
54.8 [g]
Barcode Qty 10 NR
8007352554924
10 NR
26.9x11.6x4.9 [cm]
610.4 [g]
