MASTER dimmer 230V 500VA 2M Silver - 14142.SL

Pdf

14142.SL
Wiring devices / Traditional wiring devices / PLANA / Devices

MASTER dimmer 230V 500VA 2M Silver
Dimmer 230 V~ 50/60 Hz for: 40-500 VA electronic transfomers, neutral terminal, control with built-in push button or from peripheral NO push buttons, MASTER function for 14143 und 20143 , MOSFET technology, visible in darkness, protection fuse, Silver - 2 modules

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation


Drawings

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Push button
Type of load
Capacitive load
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush-mounted
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
9006
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
230,00 - 230,01 V
Frequency
50,00 - 60,00 HZ
Control voltage
230,00 - 230,01 V
Device width
44,80 mm
Device height
49,00 mm
Device depth
43,00 mm
Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352387607
1 NR
6x5.4x5.3 [cm]
80 [g]
Barcode Qty 5 NR
8007352387614
5 NR
17.2x13.1x6 [cm]
456.6 [g]
