Antibacterial 2P+E 16A P17/11 outlet - 14203.AB

Pdf
14203.AB

Plana / Devices / Italian standard socket outlets

Antibacterial 2P+E 16A P17/11 outlet
2P+E 16 A 250 V~ SICURY Bpresa socket outlet, Italian standard P17/11, with antibacterial treatment, white

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type Bipasso
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
34,50 mm
Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352499416
1 NR
4.1x2.8x5.3 [cm]
31 [g]
Barcode Qty 50 NR
8007352499423
50 NR
21.4x11.6x14.2 [cm]
1,651 [g]
Barcode Qty 500 NR
8007352641273
500 NR
57.5x22.5x30 [cm]
17,020 [g]
