2P+E16AFR SICURYoutlet+cover screwless S - 14212.FX.C.SL

Pdf
Vimar - 14212.FX.C.SL - 2P+E16AFR SICURYoutlet+cover screwless S
Vimar - 14212.FX.C.SL - 2P+E16AFR SICURYoutlet+cover screwless S

14212.FX.C.SL
Wiring devices / Traditional wiring devices / PLANA / Devices

2P+E16AFR SICURYoutlet+cover screwless S
2P+E 16 A 250 V~ SICURY socket outlet, French standard, with cover, screwless terminals, Silver - 2 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Push-in clamp
With hinged lid
Yes
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Silver
RAL-number (similar)
9006
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
44,80 mm
Device height
49,00 mm
Device depth
35,90 mm

00. CE Marking - EU

04. NF - France

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352513198
1 NR
5x4.7x5.1 [cm]
52 [g]
Barcode Qty 10 NR
8007352513204
10 NR
24.8x10.6x6 [cm]
581.6 [g]
Barcode Qty 120 NR
8007352715219
120 NR
38.5x27x25 [cm]
6,979 [g]
