5V 2,1A USB supply unit 2M whiteCode 14295
- 14295
- Wiring devices / Traditional wiring devices / PLANA / Devices
- 5V 2,1A USB supply unit 2M white
- 5 V 2,1 A power supply unit for electronic devices, 2 USB ports supply a total of 2,1 A suitable for recharging a 2,1 A single device (e.g. tablet) or two 1 A devices simultaneously (e.g. smartphone and phablet), supply voltage 120-230 V~ 50/60 Hz, white - 2 modules
- Consumption: 230 mA at 120 V~ and 150 mA at 230 V~
- Power supply: 120-230 V~ 50/60 Hz
- The HIGH POWER socket outlet enables full-speed charging even in the most powerful devices, providing up to 2.1 A which means up to 10 W available, hence the name HIGH POWER. The device is designed to charge two devices simultaneously
- Output voltage: 5 V d.c. (± 5%) SELV
- Max output load: 2.1 A (1x2100 mA, 2x1050 mA, etc.)
- Product Status
- 2 - Will be discontinued
Sheets, Manuals, Documentation
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
USB power supply
USB power supply
Model
Bus
Bus
Operating voltage
120,00 - 230,00 V
120,00 - 230,00 V
Frequency
50,00 - 60,00 HZ
50,00 - 60,00 HZ
Max. output current
2.100 mA
2.100 mA
Mounting method
Flush-mounted
Flush-mounted
Colour
White
White
RAL-number
0
0
Min. depth of built-in installation box
36,00 mm
36,00 mm
Minimum order quantity: 1 NR
Barcode
8007352538818
1 NR
6x5.4x5.3 [cm]
68.1 [g]
8007352538825
10 NR
28.1x13.1x6 [cm]
757.9 [g]
8007352641358
120 NR
38.5x29x30 [cm]
9,576 [g]
