TV-RD-SAT through-line outlet 2outs Silv - 14302.10.SL

Pdf
14302.10.SL

Plana Silver / Devices / 2-outlet TV/RD/SAT socket outlets

TV-RD-SAT through-line outlet 2outs Silv
Coaxial TV-RD-SAT 5-2400 MHz socket outlet, through-line, demix, 2 outputs with male (TV-RD) and female F-type (SAT) connectors, connection attenuation 10 dB, Silver - 2 modules

Product Status
3 - Active

Class group
Antenna and satellite technique
Class
Antenna socket
Model
TWIN end socket
Cover
None
Tap loss at 860 MHz
11,20 dB
Tap loss at 2150 MHz
12,00 dB
Number of outlets
2
Through loss at 860 MHz
2,00 dB
Through loss at 2150 MHz
2,80 dB
Suitable for remote power supply
No
Frequency
5 - 2400 MHz
Type of fastening
Snap mounting (engagement)
Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352400832
1 NR
5.1x4.3x5.3 [cm]
80.8 [g]
Barcode Qty 10 NR
8007352400993
10 NR
26.9x11.6x4.9 [cm]
872.6 [g]
