14387.R
Wiring devices / Traditional wiring devices / PLANA / Devices
Red prismatic indicator unit white
Prismatic indicator unit, 230 V~ 3 W max, for 14770, 14771, 14776 and 14777 lamps, red diffuser, white - 2 modules. Provided without lamp
Product Status
3 - Active
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Information light signal for domestic switching devices
Information light signal for domestic switching devices
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
2
2
Lamp holder
E10
E10
With light source
No
No
Lamp type
Incandescent lamp
Incandescent lamp
With flashlight
No
No
With fixed symbol/imprint
No
No
With exchangeable symbol
No
No
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Glossy
Glossy
Colour
White
White
RAL-number (similar)
3001
3001
Transparent
No
No
Colour light source
Red
Red
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
230 V
230 V
Max. lamp power
3 W
3 W
Minimum order quantity: 10 NR
Barcode
8007352122505
1 NR
6x5.4x5.3 [cm]
41 [g]
8007352122512
10 NR
28.1x13.1x6 [cm]
485 [g]
8007352634220
120 NR
38.5x29x30 [cm]
6,300 [g]
