Frame 1M +claws grey - 14601.G

Pdf

14601.G
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 1M +claws grey
1-module mounting frame, with claws, for ø 60 mm mounting boxes, grey

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with claw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
Yes
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

43. UKCA mark - Great Britain

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352136939
1 NR
7.4x7.4x1.5 [cm]
27.27 [g]
Barcode Qty 20 NR
8007352136946
20 NR
24.4x13.9x10.1 [cm]
630.07 [g]
