Frame 2M without screws 71mm grey - 14603.G

Pdf
Vimar - 14603.G - Frame 2M without screws 71mm grey
Vimar - 14603.G - Frame 2M without screws 71mm grey

14603.G
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M without screws 71mm grey
2-module mounting frame, without screws, for 60 mm fixing centres or 56x56 mm mounting boxes, modular, 71 mm distance between centres, for horizontal or vertical installation, grey

  • Thanks to the central slots, the support can be fixed onto the wall level

Product Status
3 - Active

Drawings

view encumbered art. 14603.G
PNG DXF
rear view art. 14603.G
PNG DXF
3D view art. 14603.G
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

29. QCERT - Colombia

43. UKCA mark - Great Britain

96. Electrotechnical expert

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352136977
1 NR
7.4x7.4x1.5 [cm]
14 [g]
Barcode Qty 50 NR
8007352136984
50 NR
28.6x24.8x9.6 [cm]
860.93 [g]
Barcode Qty 300 NR
8007352641327
300 NR
62x26x30 [cm]
5,780 [g]
