1P16AX reversing switch luminescent grey - 16013.F

Pdf

16013.F
Wiring devices / Traditional wiring devices / IDEA / Devices

1P16AX reversing switch luminescent grey
1P 16 AX 250 V~ reversing switch, with luminescent indicator, grey

Product Status
2 - Will be discontinued

Drawings

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
24,80 mm
Device height
50,10 mm
Device depth
39,30 mm
Built-in depth
25,50 mm

00. CE Marking - EU

14. TSE - Turkey

37. Marking - Morocco

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352003743
1 NR
4.1x2.8x5.3 [cm]
35.33 [g]
Barcode Qty 20 NR
8007352000537
20 NR
21.4x11.6x6 [cm]
765.27 [g]
