2P 16AX 1-way switch luminescent white - 16016.F.B

Pdf
16016.F.B

Idea / Devices / Basic devices

2P 16AX 1-way switch luminescent white
2P 16 AX 250 V~ 1-way switch, with luminescent indicator, white

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (akin)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
24,80 mm
Height of device
50,10 mm
Depth of device
39,30 mm
Built-in depth
25,50 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352066779
1 NR
5.1x2.8x5.3 [cm]
35.6 [g]
Barcode Qty 20 NR
8007352066786
20 NR
27x11.6x6 [cm]
782.63 [g]
