1P NO 10A push general symb.lums 3M grey - 16090.G

Pdf

16090.G
Wiring devices / Traditional wiring devices / IDEA / Devices

1P NO 10A push general symb.lums 3M grey
1P NO 10 A 250 V~push button, general symbol, luminous, for signalling unit, grey - 3 modules. Provided without signalling unit

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
300
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
24,80 mm
Device height
50,10 mm
Device depth
36,10 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

19. NOM - Mexico

37. Marking - Morocco

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352090750
1 NR
5.3x3.9x7.6 [cm]
46.53 [g]
Barcode Qty 20 NR
8007352090767
20 NR
28.1x13.1x11.3 [cm]
1,033.87 [g]
