1PNO 10A push general symb.lums 2M white - 16090.M.B

Pdf

Vimar - 16090.M.B - 1PNO 10A push general symb.lums 2M white

16090.M.B
Wiring devices / Traditional wiring devices / IDEA / Devices

1PNO 10A push general symb.lums 2M white
1P NO 10 A 250 V~ push button, general symbol, luminous, for signalling unit, white - 2 modules. Provided without signalling unit

Product Status
3 - Active

Drawings

view encumbered art. 16090.M.B

PNG DXF

rear view art. 16090.M.B

PNG DXF

3D view art. 16090.M.B

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
200

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9001

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
48,80 mm

Device height
50,10 mm

Device depth
36,10 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

8007352097049

1 NR

5.1x4.3x5.3 [cm]

34.53 [g]

8007352097056

20 NR

26.9x11.6x9 [cm]

779.33 [g]
