2P+E 16A universal outlet white - 16211.B

Pdf
16211.B

Idea / Devices / Italian standard socket outlets

2P+E 16A universal outlet white
2P+E 16 A 250 V~ SICURY socket outlet, universal, P40 Italian standard, white - 2 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Other
With built-in USB power supply
No
Number of units
1
Number of modules (module syst
2
Number of socket outlets switc
0
Imprint/indication
Without imprint
Connection type
Screwed terminal
With hinged lid
No
With child-protection
Yes
Label space/information surfac
Yes
Colour
White
RAL-number (akin)
9001
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protect
IP20
For heavy conditions (in accor
No
Impact strength
Other
Width of device
49,80 mm
Height of device
50,10 mm
Depth of device
36,00 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352147591
1 NR
5.1x4.3x5.3 [cm]
45.06 [g]
Barcode Qty 20 NR
8007352147607
20 NR
26.9x11.6x9 [cm]
1,092.93 [g]
Barcode Qty 240 NR
8007352641013
240 NR
38x28.5x35.5 [cm]
13,644 [g]
