16 A connected actuator white - 16493.B

16493.B

Idea / Devices / Radiofrequency

16 A connected actuator white
View Wireless electronic control device with NO 16 A 100-240 V~ 50/60 Hz relay output, local control with push button or remote control, double IoT technology on Bluetooth 5.0 standard for the creation of View Wireless mesh system and on Zigbee 3.0 standard, function for measuring the instant power and energy consumed and load cut-off threshold, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, white

  • Configuration from View Wireless App for Bluetooth technology system and Amazon App for Zigbee technology
  • Compatible with Alexa, Google Home and IFTTT, using the dedicated gateway or Zigbee hub

Product Status
3 - Active

Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX radio
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
Yes
Mounting method
Flush mounted (plaster)
Width in number of modular spa
1
Local operation/hand operation
Yes
With LED indication
Yes
Suitable for C-load
Yes
Max. number of switching conta
1
Rated current
16 A
Rated operating voltage
230,00 - 230,01 v
Different phases connectable
No
Bus connection included
Yes
Modular expandability
No
Degree of protection (IP)
IP40
Minimum order quantity: 1 NR

Barcode

8007352642973
1 NR
6x5.4x5.2 [cm]
59.8 [g]
8007352649866
60 NR
37.5x30x13.5 [cm]
3,930 [g]
