16967.1
Idea / Systems / Domotics - devices
Two rocker butt.+roller laths actuator g
Two rocker push buttons and actuator for 1 roller shutter laths positioning, relay output for cosφ 0.6 2 A 120-230 V~ motor, to complete with interchangeable 1- or 2-module buttons, grey - 2 modules
Product Status
42 - Will be discontinued
Sheets, Manuals, Documentation
Drawings
Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Contacts
Other
Number of poles
1
Feedback-signal contact
No
Number of rockers
2
Number of modules (module syst
2
With lighting
Yes
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (akin)
9001
Transparent
No
Label space/information surfac
Yes
Imprint
None
Suitable for degree of protect
IP40
Nominal voltage
230 v
Rated current
2,00 A
Width of device
49,80 mm
Height of device
50,10 mm
Depth of device
44,80 mm
10. EAC Eurasian Customs Union
Minimum order quantity: 1 NR
Barcode
8007352434066
1 NR
11.2x9.6x9.8 [cm]
137.53 [g]
Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see conditions of use.
