2P 32A 1-way switch Metal - 19017.M

Pdf
Vimar - 19017.M - 2P 32A 1-way switch Metal
Vimar - 19017.M - 2P 32A 1-way switch Metal

19017.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2P 32A 1-way switch Metal
2P 32 A 250 V~ 1-way switch, lightable, with built-in frame for British standard square boxes, to complete with British standard cover plates, Metal. Max 200 W for integrated ballast lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Lighting
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
32,00 A
Monitoring contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Device width
84,30 mm
Device height
82,50 mm
Device depth
32,20 mm
Built-in depth
22,50 mm

00. CE Marking - EU

08. ASTA - UK

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352592865
1 NR
8.5x3.9x8.6 [cm]
116.8 [g]
Barcode Qty 10 NR
8007352592872
10 NR
20.7x18.5x9.6 [cm]
1,284 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
