Switched conn.unit 13A+warning unitwhite - 19049.L.B

19049.L.B
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Switched conn.unit 13A+warning unitwhite
2P switched 13 A 250 V~ connection unit, protection fuse, with built-in mounting frame for installation in British standard square flush mounting boxes and to complete with 3-module British standard cover plates, white

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (2022 kb)

Video

• Arké lives in your time

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
2-pole switch

Method of operation
Rocker/button

Number of modules (module system)
3

Push button switch
Yes

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Surface protection
Lacquered

Surface finishing
Matt

Colour
White

RAL-number (similar)
9016

Label space/information surface
Yes

Rated current
13,00 A

Monitoring contact
No

Washing machine switch
No

Device height
82,50 mm

00. CE Marking - EU

08. ASTA - UK

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

---

Barcode

8007352590168

1 NR

8.5x3.9x8.6 [cm]

109.6 [g]

8007352590175

10 NR

20.7x18.5x9.6 [cm]

1,212 [g]
