2P 10A 2-way push button white - 19061.B

Pdf
19061.B

Arké white / Devices / Devices - other functions

2P 10A 2-way push button white
2P 10 A 250 V~ 2-way push button (6 terminals) with directional arrows and central OFF position, white

Product Status
3 - Active

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
1
Number of poles
2
Nominal voltage
250 v
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
44,20 mm
Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352571334
1 NR
5.1x2.8x5.3 [cm]
42.7 [g]
Barcode Qty 10 NR
8007352571341
10 NR
14.4x11.6x6 [cm]
472 [g]
