2 interlock.1PNO+NO10A pushes antibact.g - 19062.AB

Pdf
19062.AB

Arké / Devices / Devices - other functions

2 interlock.1PNO+NO10A pushes antibact.g
Two interlocked push buttons, 1P NO + 1P NO 10 A 250 V~, with directional arrows, antibacterial material, grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
1
Number of poles
1
Nominal voltage
250 v
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
Yes
Surface protection
Other
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
38,40 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352652422
1 NR
4.1x2.8x5.3 [cm]
32.9 [g]
Barcode Qty 20 NR
8007352652439
20 NR
21.4x11.6x6 [cm]
739 [g]
Barcode Qty 460 NR
8007352653788
460 NR
57.5x22.5x30 [cm]
17,004 [g]
