19062.AB.B
Wiring devices / Traditional wiring devices / ARKÉ / Devices
2 interlock.1PNO+NO10A pushes antibact.w
Two interlocked push buttons, 1P NO + 1P NO 10 A 250 V~, with directional arrows, antibacterial material, white
Product Status
3 - Active
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Push button
Push button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Model
Other
Other
Method of operation
Push button
Push button
Number of rockers
1
1
Number of modules (module system)
100
100
Number of poles
1
1
Nominal voltage
250 V
250 V
Rated current
10,00 A
10,00 A
With lighting
No
No
Feedback-signal contact
No
No
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Anti-bacterial treatment
Yes
Yes
Surface protection
Other
Other
Surface finishing
Matt
Matt
Colour
White
White
RAL-number (similar)
9016
9016
Transparent
No
No
Label space/information surface
Yes
Yes
Suitable for degree of protection (IP)
IP40
IP40
Device width
22,30 mm
22,30 mm
Device height
49,00 mm
49,00 mm
Device depth
38,40 mm
38,40 mm
Minimum order quantity: 20 NR
Barcode
8007352652446
1 NR
4.1x2.8x5.3 [cm]
32.9 [g]
8007352652453
20 NR
21.4x11.6x6 [cm]
739 [g]
8007352653795
460 NR
57.5x22.5x30 [cm]
17,004 [g]
