Two independent NO+NO 10A pushes Metal - 19066.M

Pdf
Vimar - 19066.M - Two independent NO+NO 10A pushes Metal
Vimar - 19066.M - Two independent NO+NO 10A pushes Metal

19066.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Two independent NO+NO 10A pushes Metal
Two independent push buttons, 1P NO + 1P NO 10 A 250 V~, Metal. They allow the simultaneous closing of the two circuits and are thus not suitable for reversing motors (roller blinds, gates, etc.)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
2
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
Monitoring contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
39,20 mm

00. CE Marking - EU

01. IMQ - Italy

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352593732
1 NR
4.1x2.8x5.3 [cm]
33 [g]
Barcode Qty 20 NR
8007352593749
20 NR
21.4x11.6x6 [cm]
718.6 [g]
Barcode Qty 460 NR
8007352758582
460 NR
57.5x22.5x30 [cm]
17,047.8 [g]
