2P 16AX 1-way sw.+000-key Metal - 19083.CU.M

Pdf
19083.CU.M

Arké Metal / Devices / Devices - other functions

2P 16AX 1-way sw.+000-key Metal
2P 16 AX 250 V~ key-operated 1-way switch, 000 unified key removable in both positions, Metal. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Key
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
22,20 mm
Height of device
49,00 mm
Depth of device
43,50 mm
Built-in depth
33,00 mm

00. CE Marking - EU

01. IMQ - Italy

04. NF - France

10. EAC Eurasian Customs Union

14. TSE - Turkey

37. Marking - Morocco

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352600744
1 NR
5.1x2.8x5.3 [cm]
55.8 [g]
Barcode Qty 20 NR
8007352601086
20 NR
27x11.6x6 [cm]
1,188.8 [g]
