19100.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices
Axial 1P 10AX 1-way switch Metal
Product Status
3 - Active
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Wiring system
Off switch 1-pole
Off switch 1-pole
Method of operation
Rocker/button
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
1
1
Push button switch
Yes
Yes
Number of rockers
1
1
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
With mounting plate
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Lacquered
Lacquered
Surface finishing
Matt
Matt
Colour
Aluminium
Aluminium
RAL-number (similar)
9007
9007
Label space/information surface
Yes
Yes
Lighting
Optional
Optional
Function lighting
Control and orientation
Control and orientation
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
250 V
250 V
Rated current
10,00 A
10,00 A
Monitoring contact
No
No
Connection type
Screwed terminal
Screwed terminal
Washing machine switch
No
No
00. CE Marking - EU
01. IMQ - Italy
29. QCERT - Colombia
36. ISI - India
37. Marking - Morocco
37. Marking - Morocco
Minimum order quantity: 20 NR
Barcode
8007352685000
1 NR
5.1x2.8x5.3 [cm]
28.6 [g]
8007352685017
20 NR
27x11.6x6 [cm]
637.4 [g]
8007352685024
120 NR
37.5x30x13.5 [cm]
4,184.4 [g]
