2P+E 16A P17/11 outlet Metal - 19203.M

Pdf
19203.M

Arké Metal / Devices / Italian standard socket outlets

2P+E 16A P17/11 outlet Metal
2P+E 16 A 250 V~ SICURY Bpresa socket outlet, Italian standard P17/11, Metal

Product Status
3 - Active

You may also be interested in

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type Bipasso
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Aluminium
RAL-number (similar)
9007
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
34,50 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

19. NOM - Mexico

37. Marking - Morocco

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352595705
1 NR
4.1x2.8x5.3 [cm]
29.8 [g]
Barcode Qty 50 NR
8007352595712
50 NR
21.6x11.6x14.3 [cm]
1,604 [g]
Barcode Qty 500 NR
8007352595729
500 NR
57.5x22.5x30 [cm]
16,041 [g]
Barcode Qty 10,500 NR
8007352613386
10,500 NR
120x80x103 [cm]
353,010 [g]
