Two switch.2P+E 13A English outlet Metal - 19222.L.M

Pdf
Vimar - 19222.L.M - Two switch.2P+E 13A English outlet Metal
Vimar - 19222.L.M - Two switch.2P+E 13A English outlet Metal

19222.L.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Two switch.2P+E 13A English outlet Metal
Two 2P switched 2P+E 13 A 250 V~ SICURY socket outlets, English standard with indicator unit, with built-in frame for British standard mounting boxes, to complete with 5-module British standard cover plate, Metal

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
British Standard
Number of modules (module system)
5
Number of socket outlets switchable
2
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Aluminium
RAL-number (similar)
9007
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
Yes
With orientation lighting
No
Overvoltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
With loop through function
No
With on/off switch
Yes
Rotated central insert
No
Nominal current
13 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
144,00 mm
Device height
82,50 mm
Device depth
29,50 mm

00. CE Marking - EU

08. ASTA - UK

26. SASO - Saudi Arabia

30. G-Mark - Gulf Countries

37. Marking - Morocco

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352592780
1 NR
8.5x3.5x15 [cm]
163.5 [g]
Barcode Qty 5 NR
8007352592797
5 NR
17.5x16.3x9.8 [cm]
898.5 [g]
