19255.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices
2P+E13A SICURY multi-outlet+switch Metal
2P+E 13 A 250 V~ SICURY socket outlet, multi standard with 1P 1-way switch, lightable, Metal - 3 modules
Product Status
3 - Active
Sheets, Manuals, Documentation
Video
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Socket outlet
Socket outlet
Model
Other
Other
Number of modules (module system)
2
2
Number of socket outlets switchable
1
1
Imprint/indication
None
None
Connection type
Screwed terminal
Screwed terminal
With hinged lid
No
No
With enhanced contact protection
Yes
Yes
Label space/information surface
Yes
Yes
Colour
Aluminium
Aluminium
RAL-number (similar)
9007
9007
Metallic colour
No
No
Transparent
No
No
Lockable
No
No
Eject-mechanism
No
No
Insulated mounting
No
No
With function lighting
Yes
Yes
With orientation lighting
No
No
Overvoltage protection
No
No
Fault current protection
No
No
Mounting method
Flush-mounted
Flush-mounted
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Lacquered
Lacquered
Surface finishing
Matt
Matt
With loop through function
No
No
With on/off switch
Yes
Yes
Rotated central insert
No
No
Nominal current
13 A
13 A
Nominal voltage
250 V
250 V
Frequency
50,00 - 60,00 HZ
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
IP20
Impact strength
Other
Other
Device width
67,30 mm
67,30 mm
Device height
49,00 mm
49,00 mm
Device depth
31,10 mm
31,10 mm
00. CE Marking - EU
00. CE Marking - EU
37. Marking - Morocco
92. RoHS UAE
Minimum order quantity: 10 NR
Barcode
8007352599444
1 NR
5.3x3.9x7.6 [cm]
66 [g]
8007352599451
10 NR
28.1x13.1x6 [cm]
739.2 [g]
8007352717312
120 NR
38.5x29x30 [cm]
8,870.4 [g]
Share
Legal
Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
