F type female socket connector Metal - 19318.M

19318.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

F type female socket connector Metal
Coaxial socket outlet with F type (IEC 60169-24) female connector, Metal. For frequencies up to 2400 MHz. In/out connection with F type male connector (01654)

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Video

• Arké lives in your time

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Antenna and satellite technique

Class
Antenna socket box

Model
End socket

Cover
None

Number of outlets
1

Suitable for remote power supply
Yes

Type of fastening
Snap mounting (engagement)

Colour
Aluminium

RAL-number (similar)
9007

Surface protection
Lacquered

Material
Plastic

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

---

Barcode

8007352594623

1 NR

4.1x2.8x5.3 [cm]

13.4 [g]

8007352594630

10 NR

14.4x9x6 [cm]

171.9 [g]
