RJ11 phone jack 6/4 antibacterial white - 19320.AB.B

Pdf
19320.AB.B

Arké white / Devices / Phone socket outlets

RJ11 phone jack 6/4 antibacterial white
RJ11 phone jack, 6-position 4-conductor (6/4), screw terminals, antibacterial material, white

Product Status
3 - Active

Class group
Domestic switching devices
Class
Insert/cover for communication technolog
Assembly arrangement
Modular device for domestic switching devices
Utilization
UAE/IAE (ISDN)
Support ring
No
With dust cover
No
With hinged lid
No
With imprint
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Other
Surface finishing
Matt
Colour
White
RAL-number (akin)
9016
Transparent
No
Type of fastening
Clamp mounting
Number of modules (module syst
1
With strain relief
No
Luster terminal
No
Suitable for degree of protect
IP20
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
43,10 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352652262
1 NR
5.1x2.8x5.3 [cm]
21.6 [g]
Barcode Qty 20 NR
8007352652279
20 NR
27x11.6x6 [cm]
501.3 [g]
Barcode Qty 120 NR
8007352653931
120 NR
37.5x30x13.5 [cm]
3,367.8 [g]
