2P 6A 24V SELV outlet grey - 19330

Pdf
19330

Arké / Devices / Socket outlets for signal reception

2P 6A 24V SELV outlet grey
2P 6 A 24 V (SELV) socket outlet for plug 01620 (pins ø 3 mm, distance between centres 12,4 mm), grey. For auxiliary circuits.

Product Status
3 - Active

Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Utilization
Other
Support ring
No
With dust cover
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (akin)
7015
Transparent
No
Number of modules (module system)
1
With strain relief
No
Luster terminal
No
Suitable for degree of protection (IP)
IP20
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
34,70 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352450653
1 NR
4.1x2.8x5.3 [cm]
23.7 [g]
Barcode Qty 20 NR
8007352450660
20 NR
21.4x11.6x6 [cm]
530.5 [g]
