1P+N C16 120-230V CB Metal - 19405.16.M

Pdf
19405.16.M

Arké Metal / Devices / Current breaker switches (CBs)

1P+N C16 120-230V CB Metal
1P+N C 16 circuit breaker, supply voltage 120-230 V~ 50-60 Hz, breaking capacity 3000 A, Metal

Product Status
3 - Active

Class group
Circuit breakers and fuses
Class
Earth leakage circuit breaker
Number of poles (total)
2
Number of protected poles
1
Rated voltage
230 v
Rated current
16 A
Rated fault current
16 A
Leakage current type
A
Current limiting class
1
Rated short-circuit breaking capacity Icn acc. EN 61009-1
3,00 kA
Voltage type
AC
Frequency
50/60 Hz
Release characteristic
C
Concurrently switching N-neutral
Yes
Over voltage category
3
Built-in depth
38,00 mm
Suitable for flush-mounted installation
Yes
Anti-nuisance tripping version
No
Degree of protection (IP)
IP40
Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352600416
1 NR
6x2.8x5.3 [cm]
53.4 [g]
Barcode Qty 10 NR
8007352600423
10 NR
14.4x13.1x6 [cm]
582.3 [g]
