Relay actuator 1M Metal - 19534.M

19534.M

Arké Metal / Systems / Domotics - devices

Relay actuator 1M Metal
Actuator with 6 A 120-230 V~ change-over relay output, Metal

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data
• Ask a question

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (1563 kb)
• By-me automation-fw Compatibility (206 kb)

Video

• Arké lives in your time

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Switch actuator for bus system

Bus system KNX
No

Bus system KNX radio
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
None

Radio frequent bidirectional
No

Mounting method
Flush mounted (plaster)

Local operation/hand operation
No

With LED indication
Yes

Suitable for C-load
Yes

Max. number of switching contacts
1

Rated current
6 A

Rated operating voltage
120,00 - 230,00 v

Different phases connectable
No

With bus connection
Yes

Modular expandability
No

Degree of protection (IP)
IP40

00. CE Marking - EU

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352597402

1 NR

5.1x4.3x5.3 [cm]

55 [g]

8007352597419

5 NR

14.4x11.6x6 [cm]

325.6 [g]

8007352648289

60 NR

36.5x33x13.5 [cm]

4,320 [g]
