19583.M
Smart systems&products / By-me Plus / ARKÉ / Devices
Speaker connector Metal
Spring connector for speaker, Metal
Product Status
3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Insert/cover for communication technology
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Utilization
Other
Other
Support ring
No
No
With dust cover
No
No
With hinged lid
No
No
With imprint
Yes
Yes
Mounting method
Flush-mounted
Flush-mounted
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Lacquered
Lacquered
Surface finishing
Matt
Matt
Colour
Aluminium
Aluminium
RAL-number (similar)
9007
9007
Transparent
No
No
Type of fastening
Engage (snap)
Engage (snap)
Number of modules (module system)
1
1
With strain relief
No
No
Luster terminal
No
No
Suitable for degree of protection (IP)
IP20
IP20
Device width
22,20 mm
22,20 mm
Device height
49,00 mm
49,00 mm
Device depth
29,90 mm
29,90 mm
Minimum order quantity: 1 NR
Barcode

8007352597341
1 NR
5.1x4.3x5.3 [cm]
22.1 [g]

8007352597358
10 NR
26.9x11.6x4.9 [cm]
290.6 [g]

8007352648326
200 NR
47.5x27x29 [cm]
6,320 [g]
