19643.B06
Wiring devices / Traditional wiring devices / ARKÉ / Cover plates
Plate 4M (2+2x71) metal polar TL
Product Status
3 - Active
Class group
Domestic switching devices
Domestic switching devices
Class
Cover frame for domestic switching devices
Cover frame for domestic switching devices
Number of units
4
4
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of units horizontal
4
4
Number of units vertical
1
1
Number of modules horizontal (module system)
4
4
Number of modules vertical (module system)
1
1
With mounting grid
Yes
Yes
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
Yes
Yes
Suitable for wall duct
Yes
Yes
Suitable for built-in installation
Yes
Yes
Label space/information surface
Yes
Yes
Material
Metal
Metal
Material quality
Other
Other
Halogen free
Yes
Yes
Anti-bacterial treatment
No
No
Surface protection
Lacquered
Lacquered
Surface finishing
Glossy
Glossy
Colour
White
White
RAL-number (similar)
9016
9016
Transparent
No
No
With hinged lid
No
No
Degree of protection (IP)
IP00
IP00
Type of fastening
Clamp mounting
Clamp mounting
Width
161,00 mm
161,00 mm
Height
90,00 mm
90,00 mm
Depth
8,60 mm
8,60 mm
Built-in width
161,00 mm
161,00 mm
Built-in height
0,00 mm
0,00 mm
Minimum order quantity: 1 NR
Barcode
8007352722866
1 NR
16.8x9.7x1.7 [cm]
167.2 [g]
8007352722873
5 NR
17.7x10.3x10.7 [cm]
901.4 [g]
