Plate 6M (2+2+2x71) metal polar TL - 19644.B06

Pdf

19644.B06
Wiring devices / Traditional wiring devices / ARKÉ / Cover plates

Plate 6M (2+2+2x71) metal polar TL

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
6
Mounting direction
Horizontal and vertical
Number of units horizontal
6
Number of units vertical
1
Number of modules horizontal (module system)
6
Number of modules vertical (module system)
1
With mounting grid
Yes
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9016
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
232,00 mm
Height
90,00 mm
Depth
8,60 mm
Built-in width
232,00 mm
Built-in height
0,00 mm

00. CE Marking - EU

29. QCERT - Colombia

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352722880
1 NR
24x9.7x1.7 [cm]
232.5 [g]
Barcode Qty 5 NR
8007352722897
5 NR
24.8x10.3x10.7 [cm]
1,248 [g]
