Vimar - 20008.2.N - 1P NO 10A push button 2M Next
Vimar - 20008.2.N - 1P NO 10A push button 2M Next
20008.2.N

Eikon Next / Devices / Basic devices

1P NO 10A push button 2M Next
1P NO 10 A 250 V~ push button, lightable, replaceable button, Next - 2 modules

Product Status
3 - Active

Drawings

view encumbered art. 20008.2.N
PNG DXF
rear view art. 20008.2.N
PNG DXF
3D view art. 20008.2.N
PNG DXF
Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
2
Number of poles
1
Nominal voltage
250 v
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
36,10 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352285576
1 NR
5.1x4.3x5.3 [cm]
34.2 [g]
Barcode Qty 20 NR
8007352285583
20 NR
26.9x11.6x9 [cm]
764.07 [g]
Barcode Qty 240 NR
8007352646827
240 NR
38x28.5x35.5 [cm]
9,528 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
