1P NO 10A push button screwless grey - 20008.FX

Pdf
Vimar - 20008.FX - 1P NO 10A push button screwless grey
Vimar - 20008.FX - 1P NO 10A push button screwless grey
20008.FX

Eikon / Devices / Basic devices

1P NO 10A push button screwless grey
1P NO 10 A 250 V~ push button, screwless terminals, lightable, replaceable button, grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
1
Number of poles
1
Nominal voltage
250 v
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
37,90 mm

00. CE Marking - EU

04. NF - France

09. VDE - Germany

10. EAC Eurasian Customs Union

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352515734
1 NR
5.1x2.8x5.3 [cm]
25.5 [g]
Barcode Qty 50 NR
8007352515741
50 NR
27x15x12 [cm]
1,370 [g]
