1P NO 10A push+white indicator Next - 20068.B.N

Pdf

20068.B.N
Wiring devices / Traditional wiring devices / EIKON / Devices

1P NO 10A push+white indicator Next
1P NO 10 A 250 V~ push button + indicator unit for signalling unit, white diffuser, Next. Provided without signalling unit

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
38,50 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

20. IQC - Argentina

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352291614
1 NR
4.1x2.8x5.3 [cm]
31.4 [g]
Barcode Qty 10 NR
8007352291621
10 NR
14.4x9x6 [cm]
349.53 [g]
Barcode Qty 160 NR
8007352644953
160 NR
37.5x30x13.5 [cm]
4,926 [g]
