Universal MASTER dimmer 230V Next - 20135.1.N

Pdf

20135.1.N
Wiring devices / Traditional wiring devices / EIKON / Devices

Universal MASTER dimmer 230V Next
Universal-dimmer 230 V~ 50 Hz, phase-cutting, for: 40-400 W incandescent lamps, 40-300 VA electronic transfomers, 10-200 W CFL lamps, 3-200 W LED lamps and LED phase-cutting electronic transfomers, ON/OFF control and built-in or from NO peripheral push buttons regulation, MASTER function for 20137, minimum brightness regulation, visible in darkness, Next. Not for Isoset enclosures

Product Status
3 - Active

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Push button
Type of load
Universal and LED Retrofit
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush-mounted
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
230,00 - 230,01 V
Frequency
50,00 - 50,01 HZ
Control voltage
230,00 - 230,01 V
Connection type
Screwed terminal
Device width
22,30 mm
Device height
49,00 mm
Device depth
50,70 mm

00. CE Marking - EU

31. TISI - Thailand

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352555891
1 NR
5.1x4.3x5.3 [cm]
55 [g]
Barcode Qty 10 NR
8007352555907
10 NR
26.9x11.6x4.9 [cm]
614 [g]
