MASTER dimmer 120-230V Next - 20148.N

Pdf
20148.N

Eikon Next / Devices / Electronic devices

MASTER dimmer 120-230V Next
Dimmer, supply voltage 120-230 V~ 50-60 Hz for: 40-500/40-800 W incandescent lamps and 40-300/40-500 VA ferromagnetic transformers, control and regulation with built-in or from peripheral NO push buttons, MASTER function, TRIAC technology, visible in darkness, Next

Product Status
3 - Active

Sheets, Manuals, Documentation


Drawings

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Push button
Type of load
Inductive load
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
120,00 - 230,00 v
Frequency
50,00 - 60,00 HZ
Control voltage
120,00 - 230,00 v
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
52,40 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

92. RoHS UAE

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352291249
1 NR
5.1x4.3x5.3 [cm]
52.53 [g]
Barcode Qty 10 NR
8007352291256
10 NR
26.9x11.6x4.9 [cm]
589.07 [g]
